Cabro Making Machine
Cabro Making Machine higher productivity than other small cabro making machines. This cabro making machine is based on our company's production of block forming machines, combined with foreign advanced technology and customers' real use feedback over the years, and integrates our company's many years of mobile cabro machine manufacturing experience. This is a relatively mature model. It is ahead of other domestic mobile cabro making machines of the same type.
This kind of mobile cabro making machine has many advantages such as more reasonable design, convenient operation, high forming rate, low maintenance rate, low noise and low energy consumption. cabro making machine is ahead of other domestic mobile brick machines of the same type.
Advanced technology makes the design of the host reasonable, and realizes the vibration of the box, hydraulic demoulding, electric walking, and auxiliary steering, which can be easily mastered by one person. High-quality steel and precision welding make the machine last longer.
Mobile cabro making machine with low price, reliable performance, convenient operation, stability, low power consumption (equivalent to only 1/5 of the power consumption of the same output power machine), raw materials, concrete, cement, small stones, stone powder, sand, slag, construction waste, etc. can be used in the production process.
Parameters of Cabro Making Machine:
Dimension | 3200x1650x1940mm | Weight | 4500KGS |
| Concrete Block Height | 50-200mm | Rated Pressure | 21Mpa |
| Female Mould Size | 1250x400mm | Vibration Model | Vertical Mould Vibration |
Vibration Frequency | 2900r/min | Cycle Time | 25-35Sec. |
| Vibration Acceleration | 10-15g | Vibration Force | Female Mould 50KN |
Hydraulic Pump | GBT-G316 Gear Pump.Displacement16ml/r,Rated Speed 2500r/min | ||
Hydraulic Pump Motor | Y100L2-4,Power: 3kw，Rated Speed 1500r/min，Installation Mode:B5 | ||
| Hydraulic Cylinder | Female Mould Cylinder x 2 | Ø110xØ80xØ600mm | |
| Male Mould Cylinder x 2 | Ø50xØ28xØ290mm | ||
| Concrete feeder Cylinder x2 | Ø40xØ28xØ190mm | ||
| Direction Cylinderx1 | Ø63xØ30xØ60mm | ||
| Drive Motor | Walk Gear Motor x1 | XWY3-42-2.2KW Speed Ratio i=42 | |
| Vibration Motor | Y100L-2 Power:3kw Vibration Force 50kn | ||
| Total Power | 12.0kw | ||
Daily Capacity of Cabro Making Machine:
Block Type | Picture | Size（L x W x H) | Pcs./Pallet | Pcs./8 Hours |
Hollow Block |  | 400x200x200mm | 10 | 9500 |
Hollow Block |  | 400x150x200mm | 12 | 11400 |
Hollow Block |  | 400x100x200mm | 14 | 13300 |
FAQ:
1.Q: Are you a manufacturer?
We are a professional manufacturer of machines and spare parts. In addition, we can also equip exact brand spare parts according to customer requirements. We also fully welcome OEM or ODM business.
2. Q: Do you accept special orders?
A. There are also special orders because we have our own factory for design and manufacturing.
3. Q: How long is your delivery time?
A: Usually 15-25 days after receipt of payment. Of course, it also depends on your number.
4. Q: How do you ensure product quality?
Answer: Generally, our equipment is the most durable equipment in the industry, which is also the characteristic of the concrete equipment of most customers at home and abroad. With our experienced quality control team, we are striving to provide the best quality products for most of our customers. At the same time, each of our products will pass the quality test before delivery.
